Caring for Your Monitor

	CAUTION: Read and follow the before cleaning the monitor.
	CAUTION: Before cleaning the monitor, unplug the monitor power cable from the electrical outlet.

To clean your antistatic screen, lightly dampen a soft, clean cloth with
water. If possible, use a special screen-cleaning tissue or solution
suitable for the antistatic coating. Do not use benzene, thinner, ammonia, abrasive cleaners, or compressed
air.
Use a lightly-dampened, warm cloth to clean the plastics. Avoid using detergent of any
kind as some detergents leave a milky film on the plastics.
If you notice a white powder when you unpack your monitor, wipe it off
with a cloth. This white powder occurs during the shipping of the monitor.
Handle your monitor with care as darker-colored plastics may scratch and
show white scuff marks more than
lighter-colored monitor.
To help maintain the best image quality on your monitor, use a
dynamically changing screen saver and power off your monitor when not in
use.

Universal Serial Bus (USB) Interface

This monitor supports High-Speed Certified USB 2.0 interface.

	Data Rate	Power Consumption
High speed	480 Mbps	2.5W (Max., each port)
Full speed	12 Mbps	2.5W (Max., each port)
Low speed	1.5 Mbps	2.5W (Max., each port)

USB Upstream Connector

Pin Number	4-pin Side of the connector
1	DMU
2	VCC
3	DPU
4	GND

USB Downstream Connector

Pin Number	4-Pin Side of the Signal Cable
1	VCC
2	DMD
3	DPD
4	GND

USB Ports

1 upstream — rear
4 downstream — 2 on rear; 2 on right side

NOTE: USB 2.0 capability requires 2.0
capable

computer

NOTE: The
monitor’s USB interface works only when the monitor is on or in power save mode,
If you switch the monitor off and then on, attached peripherals may take a few seconds to resume normal functionality.

You can install the monitor in any Plug and Play-compatible system. The monitor automatically provides the computer system with its Extended Display Identification Data (EDID) using Display Data Channel (DDC) protocols so the system can configure itself and optimize the monitor settings. If desired,
the user can select different settings, but in most cases monitor installation is automatic.

Back View

1	VESA mounting holes (100mm) (Behind attached base plate)	Use to mount the monitor.
2	Connectors label	Indicate the positions and types of connectors.
3	Barcode serial number label	Refer to this label if you need to contact Dell for technical support.
4	Security lock slot	Use a security lock with the slot to help secure your monitor.
5	Monitor Lock/Release Button	Press to release the stand from the monitor.
6	Regulatory rating label	List the regulatory approvals.
7	Dell Soundbar mounting brackets	Attach the optional Dell Soundbar.
8	Lock down/release button	Push the monitor down, press the button to unlock the monitor, and then lift the monitor to the desired height.
9	Cable management hole	Help organize cables by placing them through the hole.

Monitor Specifications

Model number

2007WFP

Screen type

Active matrix — TFT LCD

Screen dimensions

20.1 inches (20.1-inch viewable image size)

Preset display area:

433.4
mm (17.0 inches)

270.9
mm (10.7 inches)

Pixel pitch

0.258
mm

Viewing angle

+/- 89° (vertical) typ, +/- 89° (horizontal) typ

Luminance output

300 cd/m І(typ)

Contrast ratio

800:1 (typ)

Faceplate coating

Antiglare with hard-coating 3H

Backlight

CCFL (6) edgelight system

Response Time

16ms typical

Horizontal scan range

30 kHz to 81 kHz (automatic)

Vertical scan range

56 Hz to 76 Hz, exception 1680 x 1050 at 60 Hz only

Optimal preset resolution

1680 x 1050 at 60 Hz

Highest preset resolution

1680 x 1050 at 60 Hz

Dell guarantees image size and centering for all preset modes listed
in the following table.

Display Mode	Horizontal Frequency (kHz)	Vertical Frequency (Hz)	Pixel Clock (MHz)	Sync Polarity (Horizontal/Vertical)
VGA, 720 x 400	31.5	70.1	28.3	-/+
VGA, 640 x 480	31.5	59.9	25.2	-/-
VESA, 640 x 480	37.5	75.0	31.5	-/-
VESA, 800 x 600	37.9	60.3	40.0	+/+
VESA, 800 x 600	46.9	75.0	49.5	+/+
VESA, 1024 x 768	48.4	60.0	65.0	-/-
VESA, 1024 x 768	60.0	75.0	78.8	+/+
VESA, 1152 x 864	67.5	75.0	108.0	+/+
VESA, 1280 x 1024	64.0	60.0	108.0	+/+
VESA, 1280 x 1024	80.0	75.0	135.0	+/+
VESA, 1680 x 1050 (Digital)	64.6	59.9	119	-/+
VESA, 1680 x 1050 (Analog)	65.3	60.0	146.25	-/+

Video input signals

Analog RGB, 0.7
Volts +/-5%, 75 ohm input impedance

Digital DVI-D TMDS, 600mV for each differential line, 50 ohm
input impedance

S-video, Y input
1 volt(p-p), C input 0.286 volt(p-p), 75 ohm input impedance

Composite, 1
volt(p-p), 75 ohm input impedance

Synchronization input signals

separate horizontal and vertical, 3.3V
CMOS or 5V TTL level, positive or negative sync.

SOG (Sync on
green)

AC input voltage / frequency / current

100 to 240 VAC / 50 or
60 Hz + 3 Hz / 2.0A (Max.)

Inrush current

120V: 40A (Max.)
240V: 80A (Max.)

Signal cable type

D-sub:
Detachable, Analog, 15pin, shipped attached to the monitor
DVI-D: Detachable, Digital, 24pin, shipped detached from the
monitor S-video: Not included with display
Composite: Not included with display

Dimensions (with stand):

513.0
mm (20.2 inches)

332.0
mm (13.1 inches)

472.7
mm (18.6 inches)

177.7 mm ( 7.0
inches)

Weight

6.5 Kg (14.3
lb)

5.0 Kg (11.0
lb)

9.0 Kg (19.8
lb)

Temperature:

5° to 35°C (41° to 95°F)

Storage: 0° to 60°C (32° to 140°F) Shipping: -20° to 60°C(-4° to 140°F)

Humidity:

10% to 80% (non-condensing)

Storage: 5% to 90% (non-condensing) Shipping: 5% to
90%(non-condensing)

Altitude:

3,657.6 m (12,000 ft) max

12,192 m (40,000 ft) max

Thermal dissipation

256.0 BTU/hour (maximum)
187.66 BTU/hour (typical)

Power Management Modes

If you have VESA’s DPMS compliance display card or software installed in your PC, the monitor can
automatically reduce its power consumption when not in use. This is referred to as ‘Power Save Mode’*. If
activity from keyboard, mouse or other input devices is detected by the computer, the monitor will automatically «wake up». The following table shows the power consumption and signaling of this automatic power saving feature:

VESA Modes	Horizontal Sync	Vertical Sync	Video	Power Indicator	Power Consumption
Normal operation	Active	Active	Active	Green	75W (maximum)* 55W (normal)**
Active-off mode	Inactive	Inactive	Blanked	Amber	Less than 2 W
Switch off	—	—	—	Off	Less than 1 W (at 230 V)

* With Audio + USB ** Without Audio + USB

This monitor is ENERGY STAR-compliant as well
as TCO ’99/ TCO ’03 power management compatible.

* Zero power consumption
in OFF mode can only be achieved by disconnecting the main cable from the
monitor.

VGA Connector

Pin Number	15-pin Side of the Connected Signal Cable
1	Video-Red
2	Video-Green
3	Video-Blue
4	GND
5	Self-test
6	GND-R
7	GND-G
8	GND-B
9	Computer 5V/3.3V
10	GND-sync
11	GND
12	DDC data
13	H-sync
14	V-sync
15	DDC clock

DVI Connector

Pin Number	24—pin Side of the Connected Signal Cable
1	TMDS RX2-
2	TMDS RX2+
3	TMDS Ground
4	Floating
5	Floating
6	DDC Clock
7	DDC Data
8	Floating
9	TMDS RX1-
10	TMDS RX1+
11	TMDS Ground
12	Floating
13	Floating
14	+5V / +3.3V power
15	Self test
16	Hot Plug Detect
17	TMDS RX0-
18	TMDS RX0+
19	TMDS Ground
20	Floating
21	Floating
22	TMDS Ground
23	TMDS Clock+
24	TMDS Clock-
