Technical Specifications
-
Picture/Display
- LCD panel type
- TFT-LCD
- Backlight type
- W-LED system
- Panel Size
- 22 inch/55.9 cm
- Effective viewing area
- 473.76 (H) x 296.1 (V)
- Aspect ratio
- 16:10
- Optimum resolution
- 1680 x 1050 @ 60 Hz
- Response time (typical)
- 5
ms
- Brightness
- 250
cd/m²
- Contrast ratio (typical)
- 1000:1
- SmartContrast
- 20,000,000:1
- Pixel pitch
- 0.282 x 0.282 mm
- Viewing angle
-
- 170º (H)/160º (V)
- @ C/R > 10
- Picture enhancement
- SmartImage
- Display colours
- 16.7 M
- Scanning Frequency
- 30–83 kHz (H)/56–75 Hz (V)
- sRGB
- Yes
-
Connectivity
- Signal Input
-
- DisplayPort x 1
- DVI-D (digital, HDCP)
- VGA (Analogue)
- USB
- USB 2.0 x 2
- Sync Input
-
- Separate Sync
- Sync on Green
- Audio (In/Out)
-
- PC audio-in
- Headphone out
-
Convenience
- Built-in Speakers
- 1.5 W x 2
- User convenience
-
- SmartImage
- Volume
- PowerSensor
- Menu
- Power On/Off
- Control software
- SmartControl Premium
- OSD Languages
-
- English
- French
- German
- Italian
- Portuguese
- Russian
- Simplified Chinese
- Spanish
- Other convenience
-
- Kensington lock
- VESA mount (100 x 100 mm)
- Plug and Play Compatibility
-
- DDC/CI
- Mac OS X
- sRGB
- Windows 7/Vista/XP
-
Stand
- Height adjustment
- 110
mm
- Pivot
- 90 degree
- Swivel
- -65/65
degree
- Tilt
- -5/20
degree
-
Power
- ECO mode
- 12.6 W (typ.)
- On mode
- 14.61 W (typ.) (EnergyStar 7.0 test method)
- Standby mode
- 0.1 W
- Off mode
- Zero watts with Zero switch
- Power LED indicator
-
- Operation — White
- Standby mode — White (flashing)
- Power supply
-
- Built-in
- 100–240 VAC, 50–60 Hz
-
Dimensions
- Product with stand (mm)
- 504 x 509 x 227
mm
- Product without stand (mm)
- 504 x 349 x 59
mm
- Packaging in mm (W x H x D)
- 565 x 391 x 186
mm
-
Weight
- Product with stand (kg)
- 5.20
kg
- Product without stand (kg)
- 3.38
kg
- Product with packaging (kg)
- 7.05
kg
-
Operating conditions
- Temperature range (operation)
- 0°C to 40°C
°C
- Temperature range (storage)
- -20°C to 60°C
°C
- Relative humidity
- 20%-80
%
- Altitude
- Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
- MTBF
- 30,000
hour(s)
-
Sustainability
- Environmental and energy
-
- PowerSensor
- EnergyStar 7.0
- TCO Certified Edge
- RoHS
- Recyclable packaging material
- 100
%
- Post-consumer recycled plastic
- 65%
- Specific Substances
-
- PVC/BFR free housing
- Mercury free
-
Compliance and standards
- Regulatory Approvals
-
- BSMI
- CE Mark
- FCC Class B
- GOST
- SASO
- SEMKO
- TUV Ergo
- TUV/GS
- UL/cUL
- WEEE
-
Cabinet
- Front bezel
- Black
- Rear cover
- Black
- Foot
- Black
- Finish
- Texture
-
What’s in the box?
- Monitor with stand
- Yes
- Cables
- VGA, DVI, Audio, Power
- User Documentation
- Yes
See all specifications See less specifications
