Philips 8000 series 46PFL8606H/60 TV 116.8 cm (46″) Full HD Smart TV Wi-Fi Black
The Philips 46PFL8606H/60 TV is a model with a screen diagonal of 116.8 cm, a screen resolution of 1920 x 1080 pixels, an aspect ratio of 16:9, 4 HDMI ports to connect a Blu-ray player, DVD, a game console, etc., 2 USB ports to connect an external hard drive, a Chromecast, a Bluetooth receiver etc., Ethernet port to connect to the internet via cable, internet connection via Wi-Fi, in addition to the rest of the features listed below.
Release date: 2011-08-15.
| Exhibition | |
|---|---|
| Brand | Philips |
| Model | 46PFL8606H/60 |
| Aspect ratio | 16:9 |
| HDMI ports | 4 |
| USB supports | Yes |
| Ethernet sockets | Yes |
| USB ports | 2 |
| Ultra slim TV | No |
| Curved TV | No |
| Size diagonal | 116.8 |
| Resolution | 1920 x 1080 |
| Colour | Black |
| Image formats supported | JPEG XR |
| Video formats supported | AVI,H.264,MKV,MPEG1,MPEG2,MPEG4,VC-1,WMV9 |
| Audio formats supported | AAC,MP3,WMA |
| No. of speakers | 2 |
| Total speaker output | 28 |
| Internet access | Yes |
| Smart TV | Yes |
| Wi-Fi | Yes |
| Miracast screen mirroring support | Yes |
| Voltage requirement | 220 — 240 |
| Power consumption standby | 0.1 |
| Short description | Philips 8000 series 46PFL8606H/60, 116.8 cm (46″), 1920 x 1080 pixels, 3D, Smart TV, Wi-Fi, Black |
| Long description | Philips 8000 series 46PFL8606H/60. Display diagonal: 116.8 cm (46″), Display resolution: 1920 x 1080 pixels, HD type: Full HD. 3D. LED backlighting type: Edge-LED. Smart TV. Motion interpolation technology: PMR (Perfect Motion Rate), Display brightness: 450 cd/m², Response time: 1 ms, Native aspect ratio: 16:9. Digital signal format system: DVB-C,DVB-T. Wi-Fi, Ethernet LAN. Product colour: Black |
| HD type: | Full HD () |
| Display diagonal: | 116.8 cm (46″) |
| Display diagonal (metric): | 117 cm |
| Comb filter: | 3D |
| Contrast ratio (dynamic): | 500000:1 |
| Native refresh rate: | 60 Hz |
| Supported graphics resolutions: | 1920 x 1080 (HD 1080) |
| Supported video modes: | 1080p |
| LED backlighting type: | Edge-LED |
| Motion interpolation technology: | PMR (Perfect Motion Rate) |
| Response time: | 1 ms |
| Display brightness: | 450 cd/m² |
| Native aspect ratio: | 16:9 |
| Display resolution: | 1920 x 1080 pixels |
| Screen format adjustments: | Auto, Zoom |
| Audio | |
| Auto volume leveller: | Yes |
| RMS rated power: | 28 W |
| Number of speakers: | 2 |
| TV tuner | |
| Digital signal format system: | DVB-C,DVB-T |
| Analog signal format system: | NTSC,PAL,SECAM |
| Tuner type: | Analog & digital |
| Auto channel search: | Yes |
| Ports and Interfaces | |
| Digital audio optical out: | 1 |
| PC in (D-Sub): | Yes |
| HDMI ports quantity: | 4 () |
| Ethernet LAN (RJ-45) ports: | 1 |
| USB 2.0 ports quantity: | 2 () |
| Headphone outputs: | 1 |
| Common interface Plus (CI+): | Yes |
| VGA (D-Sub) ports quantity: | 1 |
| DVI port: | No |
| Component video (YPbPr/YCbCr) in: | 1 |
| PC Audio in: | Yes |
| SCART ports quantity: | 1 |
| Consumer Electronics Control (CEC): | Anynet+ |
| Energy monitoring | |
| Power consumption (typical): | 71 W |
| Power consumption (standby): | 0.1 W |
| AC input voltage: | 220 — 240 V |
| AC input frequency: | 50 — 60 Hz |
| Weight and measurements | |
| Depth (with stand): | 244 mm |
| Height (with stand): | 716 mm |
| Weight (with stand): | 26 kg |
| Width (without stand): | 108.8 cm |
| Depth (without stand): | 3.3 cm |
| Height (without stand): | 66.2 cm |
| Weight (without stand): | 23 kg |
| Width (with stand): | 1088 mm |
| Connection | |
| Browsing: | Yes |
| Ethernet LAN: | Y () |
| Wi-Fi: | Y () |
| Management Features | |
| Electronic Programme Guide (EPG): | Yes |
| Auto power off: | Yes |
| On/Off timer: | Yes |
| Other features | |
| Digital Living Network Alliance (DLNA) certified: | Yes |
| Built-in speaker(s): | Yes |
| Batteries included: | Yes |
| 3D: | Yes |
| Design | |
| Panel mounting interface: | 400 x 200 mm |
| On/off switch: | Yes |
| VESA mounting: | Y () |
| Product colour: | Black |
| Performance | |
| Local dimming: | No |
| Image formats supported: | JPEG XR |
| Audio formats supported: | AAC,MP3,WMA |
| Video formats supported: | AVI,H.264,MKV,MPEG1,MPEG2,MPEG4,VC-1,WMV9 |
| Teletext: | 1200 pages |
| Teletext function: | Yes |
| Smart TV | |
| Internet TV: | Yes |
| Smart TV: | Y () |
| Packaging | |
| Desktop stand: | Yes |
| Remote control included: | Yes |
| Quick start guide: | Yes |
| Manual: | Yes |
Technical Specifications
-
Ambilight
- Ambilight Features
-
- Ambilight Spectra 2
- Lounge light mode in stand-by
- ‘Sunset’ soft switch off
- Wall colour adaptive
- Ambilight Version
- 2-sided
- Ambilight light system
- LED wide color
- Dimming Function
- Manual and via Light Sensor
-
Picture/Display
- Aspect ratio
- Widescreen
- Diagonal screen size (inch)
- 46
inch
- Diagonal screen size (metric)
- 116
cm
- Color cabinet
- Seamless front glass
- Display
-
- LCD Full HD
- edge LED backlight
- Panel resolution
- 1920x1080p
- 3D
- 3D Ready*
- Brightness
- 450
cd/m²
- Picture enhancement
-
- Perfect Pixel HD Engine
- Perfect Natural Motion
- Perfect Contrast
- Perfect Colors
- Active Control + Light sensor
- 2D/3D noise reduction
- 200Hz Clear LCD
- Super Resolution
- 3D TV prepared*
- Dynamic screen contrast
- 500000:1
- Response time (typical)
- 1 (BEW)
ms
- Viewing angle
- 176º (H) / 176º (V)
- Peak Luminance ratio
- 65
%
- Screen enhancement
- Anti-Reflection coated screen
- Color processing
- 2250 trillion colors 17bit RGB
-
Supported Display Resolution
- Computer inputs
- up to 1920×1080 @ 60Hz
- Video inputs
-
- up to 1920x1080p
- 24, 25, 30, 50, 60 Hz
-
Tuner/Reception/Transmission
- Aerial Input
- 75 ohm coaxial (IEC75)
- Tuner bands
-
- Hyperband
- S-Channel
- UHF
- VHF
- Digital TV
-
- DVB Terrestrial *
- DVB-T MPEG4*
- DVB-C MPEG4*
- MHEG
- Video Playback
-
- NTSC
- SECAM
- PAL
-
Multimedia Applications
- Video Playback Formats
-
- Codec support:
- H264/MPEG-4 AVC
- MPEG-1
- MPEG-2
- MPEG-4
- WMV9/VC1
- Containers: AVI, MKV
- Music Playback Formats
-
- MP3
- WMA (v2 up to v9.2)
- AAC
- Picture Playback Formats
- JPEG
- Net TV
- Included
-
Convenience
- Ease of Installation
-
- Channel installation wizard
- Network installation wizard
- Settings assistant wizard
- Device connection wizard
- Auto detect Philips devices
- 2-in-1 Wallmount Stand
- Ease of Use
-
- Onscreen Usermanual
- Touch control buttons
- Favorite program selection
- Mozaïc channel grid
- One-stop experience button
- One-stop Home button
- Screen Format Adjustments
-
- Autofill (no black bars)
- Autozoom (original format)
- (includes 4:3, 14:9, 21:9)
- Super Zoom
- Movie expand 16:9
- Widescreen
- unscaled (1080p dot by dot)
- Multimedia
-
- DLNA media Browser
- Net TV services
- USB media browser
- Electronic Program Guide
-
- Now + Next EPG
- 8day Electronic Program Guide*
- Teletext
- 1200 page Hypertext
- Firmware upgradeable
-
- Firmware auto upgrade wizard
- Firmware upgradeable via USB
- Online firmware upgrade
-
Sound
- Output power (RMS)
- 2 x 10W, Invisible Sound
- Sound Enhancement
-
- Auto Volume Leveler
- Dynamic Bass Enhancement
- Incredible Surround
- Treble and Bass Control
- Clear Sound
-
Connectivity
- HDMI features
-
- Audio Return Channel
- Instaport fast HDMI switching
- EasyLink (HDMI-CEC)
-
- One touch play
- EasyLink
- Pixel Plus link (Philips)
- Remote control pass-through
- System audio control
- System standby
- Front / Side connections
-
- USB
- Common Interface Slot (CI-CI+)
- SD-card (Videostore)
- Ext 1 Scart
-
- Audio L/R
- CVBS in
- RGB
- HDMI 1
- HDMI v1.4 (Audio Return Ch.)
- Ext 2 Scart
-
- Audio L/R
- CVBS in
- RGB
- HDMI 2
- HDMI v1.3
- Other connections
-
- Headphone out
- S/PDIF out (coaxial)
- Ethernet-LAN RJ-45
- 3D TV connector
- HDMI 3
- HDMI v1.3
- PC network link
- DLNA 1.5 certified
- Ext 3
-
- YPbPr
- Audio L/R in
- Summary
- 4x HDMI, 1x USB, 2x SCART, 1x Ethernet, Wi-Fi ready
- VGA-in
-
- PC input
- D-sub 15
- HDMI Side
- HDMI v1.3
-
Power
- Mains power
- 220 — 240V, 50/60Hz
- Ambient temperature
- 5 °C to 35 °C
- Green label
- ECO label certified
- Standby power consumption
- <0.15 W
- Power consumption (typical)
- 84
W
- Power Saving Features
-
- 0 Watt Power-off switch
- Light sensor
- Eco mode
- Picture mute (for radio)
- Auto switch-off timer
- Eco settings menu
- Off mode power consumption
- < 0.01
- Annual energy consumption
- 122.64
kW·h
- Presence of lead
- Yes*
-
Accessories
- Included accessories
-
- Power cord
- Quick start guide
- Warranty certificate
- Remote Control
- Batteries for remote control
- Legal and safety brochure
- Net TV brochure
- Optional accessories
-
- Wireless USB adaptor (PTA01)
- 3D TV extention kit (PTA03)
- 3D TV starter kit (PTA02)
-
Dimensions
- Set Width
- 1102
mm
- Set Height
- 675
mm
- Set Depth
- 51
mm
- Product weight
- 25
kg
- Set height (with stand)
- 711
mm
- Set depth (with stand)
- 268
mm
- Product weight (+stand)
- 28
kg
- Box width
- 1342
mm
- Box height
- 909
mm
- Box depth
- 210
mm
- Stand width
- 508
mm
- Wall mount compatible
- 200 x 300 mm
