Compliance Information
DECLARATION OF CONFORMITY:
Manufacturer’s Name: Runco International, LLC
Manufacturer’s Address: 1195 NW Compton Drive, Beaverton, OR 97006-1992 hereby declares that the products Model Numbers:
CX-42HD, CX-OPAL42, CX-47HD, CX-OPAL47, CX-55HD, CX-OPAL55 and CX-65HD conform with the provisions of:
Council Directive 2004/108/EC on Electromagnetic Compatibility;
EN 55022 “Limits and methods of measurements of radio interference characteristics of information technology equipment” 1998;
EN 55024 “Limits and methods of measurements of immunity characteristics of information technology equipment” 1998; Including:
•EN 61000-4-2 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 2: Electrostatic discharge immunity test”
•EN 61000-4-3 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 3: Radiated, Radio-Frequency, Electromagnetic Field Immunity Test”
•EN 61000-4-4 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 4: Electrical fast transient/burst immunity test”
•EN 61000-4-5 «Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 5: Surge immunity test»
•EN 61000-4-6 «Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 6: Conducted disturbances induced by radio-frequency fields immunity test»
•EN 61000-4-8 «Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 8: Conducted disturbances induced by power frequency magnetic fields immunity test»
•EN 61000-4-11 «Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 11: Voltage dips, short interruptions and voltage variations immunity tests»
And:
•EN 61000-3-2 «Electromagnetic compatibility (EMC) Part 3, Section 2: Limits for harmonic current emissions (equipment input current up to and including 16 A per phase)» 2000;
•EN 61000-3-3 «Electromagnetic compatibility (EMC) Part 3, Section 3: Limitations of voltage changes, voltage fluctuations and flicker in public low-voltage supply systems, for equipment with rated current up to and including 16 A and not subject to conditional connection» 1995;
Council Directive 2006/95/EC and amended by M1 and C1 on Low Voltage Equipment Safety;
EN 60950 “Safety of information technology equipment, including electrical business equipment”
The Technical Construction file required by this Directive is maintained at the corporate headquarters of Planar Systems, Inc., 1195 NW Compton Drive, Beaverton, OR 97006.
Introduction
|
This Owner’s Manual describes how to install, set up and operate the Runco Crystal |
1.1 |
|
Series Models CX-42HD, CX-OPAL42, CX-47HD, CX-OPAL47, CX-55HD, CX-OPAL55 |
|
|
and CX-65HD Flat-Panel LCDs. |
|
|
Throughout this manual, the Runco CX-42HD, CX-OPAL42, CX-47HD, CX-OPAL47, |
|
|
CX-55HD, CX-OPAL55 and CX-65HD Flat-Panel LCDs are referred to collectively as the |
|
|
“Crystal Series LCD.” The information in this manual applies to all of these products, |
|
|
except where otherwise indicated. |
|
|
Runco has prepared this manual to help home theater installers and end users get the |
|
|
most out of the Crystal Series LCD. |
|
|
Runco has made every effort to ensure that this manual is accurate as of the date it was |
|
|
printed. However, because of ongoing product improvements and customer feedback, it |
|
|
may require updating from time to time. You can always find the latest version of this and |
|
|
other Runco product manuals on-line, at www.Runco.com. |
|
|
Runco welcomes your comments about this manual. Send them to info@runco.com. |
If You Have Comments |
|
About This Manual… |
|
|
Text Conventions: The following conventions are used in this manual, in order to clarify |
Textual and Graphic |
|
the information and instructions provided: |
Conventions |
•Remote control button identifiers are set in upper-case bold type; for example, “Press EXIT to return to the previous menu.”
•Computer input (commands you type) and output (responses that appear on-screen) is shown in monospace (fixed-width) type; for example: “To change the aspect ratio to Letterbox, type [S4E0002.”
•All keys with functional names are initial-capped, set in bold type and enclosed in angle brackets. These keys are the following: <Enter>, <Spacebar>, <Control>, <Esc> and <Tab>.
•<Enter> indicates that you may press either the RETURN or ENTER key on your computer keyboard if it has both keys.
In addition to these conventions, underlining, boldface and/or italics are occasionally used to highlight important information, as in this example:
A carriage return must be used after each command or string.
