Technical Specifications
-
Picture/Display
- LCD panel type
- IPS 3H hardness hard coating
- Backlight type
- W-LED system
- Panel Size
- 24.1 inch / 61 cm
- Effective viewing area
- 518.4 (H) x 324 (V)
- Aspect ratio
- 16:10
- Optimum resolution
- 1920 x 1200 @ 60 Hz
- Response time (typical)
- 5 ms (Grey to Grey)*
- Brightness
- 300
cd/m²
- Contrast ratio (typical)
- 1000:1
- SmartContrast
- 20,000,000:1
- Pixel pitch
- 0.270 x 0.270 mm
- Viewing angle
-
- 178º (H)/178º (V)
- @ C/R > 10
- Picture enhancement
- SmartImage
- Display colours
- 16.7 M
- Scanning Frequency
- 30 — 83 kHz (H) / 56 — 76 Hz (V)
- sRGB
- Yes
-
Connectivity
- Signal Input
-
- DVI-D (digital, HDCP)
- VGA (Analogue)
- Display Port 1.2 (w/ HDCP 1.4)
- USB
- USB 2.0 x 4
- Sync Input
-
- Separate Sync
- Sync on Green
- Audio (In/Out)
-
- Headphone out
- PC audio-in
-
Convenience
- Built-in Speakers
- 1.5 W x 2
- User convenience
-
- PowerSensor
- SmartImage
- Volume
- Menu
- Power On/Off
- Control software
- SmartControl
- OSD Languages
-
- English
- French
- German
- Italian
- Portuguese
- Russian
- Simplified Chinese
- Spanish
- Other convenience
-
- Kensington lock
- VESA mount (100 x 100 mm)
- Plug and Play Compatibility
-
- DDC/CI
- Mac OS X
- sRGB
- Windows 8/7/Vista
-
Stand
- Height adjustment
- 130
mm
- Pivot
- 90 degree
- Swivel
- -65/65
degree
- Tilt
- -5/20
degree
-
Power
- ECO mode
- 12.3 W (typ.)
- On mode
- 18.3 W (typ.) (EnergyStar 7.0 test method)
- Standby mode
- <0.3 W (typ.)
- Off mode
- Zero watts with Zero switch
- Power LED indicator
-
- Operation — White
- Standby mode — White (flashing)
- Power supply
-
- 100-240 VAC, 50-60 Hz
- Built-in
-
Dimensions
- Product with stand (mm)
- 555 x 550 x 244
mm
- Product without stand (mm)
- 555 x 388 x 65
mm
- Packaging in mm (W x H x D)
- 632 x 457 x 286
mm
-
Weight
- Product with stand (kg)
- 6.97
kg
- Product without stand (kg)
- 4.64
kg
- Product with packaging (kg)
- 9.80
kg
-
Operating conditions
- Temperature range (operation)
- 0°C to 40°C
°C
- Temperature range (storage)
- -20°C to 60°C
°C
- Relative humidity
- 20%–80%
%
- Altitude
- Operation: +12,000 ft (3658 m), Non-operation: +40,000 ft (12,192 m)
- MTBF (demonstrated)
- 50,000 hrs (excluded backlight)
-
Sustainability
- Environmental and energy
-
- EnergyStar 7.0
- EPEAT Gold*
- PowerSensor
- RoHS
- Recyclable packaging material
- 100
%
- Recycled material
- 25%
- Specific Substances
-
- PVC/BFR free housing
- Mercury free
- Lead free
-
Compliance and standards
- Regulatory Approvals
-
- BSMI
- CE Mark
- FCC Class B
- GOST
- SEMKO
- TUV Ergo
- TUV/GS
- UL/cUL
- WEEE
- TCO 7.0
-
Cabinet
- Front bezel
- Black
- Rear cover
- Black
- Foot
- Black
- Finish
- Texture
-
What’s in the box?
- Monitor with stand
- yes
- Cables
- VGA, DVI, DP, Audio, Power
- User Documentation
- yes
See all specifications See less specifications
Technical Specifications
-
Picture/Display
- LCD panel type
- IPS 3H hardness hard coating
- Backlight type
- W-LED system
- Panel Size
- 24.1 inch / 61 cm
- Effective viewing area
- 518.4 (H) x 324 (V)
- Aspect ratio
- 16:10
- Optimum resolution
- 1920 x 1200 @ 60Hz
- Response time (typical)
- 5 ms (Gray to Gray)*
- Brightness
- 300
cd/m²
- Contrast ratio (typical)
- 1,000:1
- SmartContrast
- 20,000,000 :1
- Pixel pitch
- 0.270 x 0.270 mm
- Viewing angle
-
- 178º (H) / 178º (V)
- @ C/R > 10
- Picture enhancement
- SmartImage
- Display colors
- 16.7 M
- Scanning Frequency
- 30 — 83 kHz (H) / 56 — 76 Hz (V)
- sRGB
- Yes
-
Connectivity
- Signal Input
-
- DVI-D (digital, HDCP)
- VGA (Analog )
- Display Port 1.2 (w/ HDCP 1.4)
- USB
- USB 2.0 x 4
- Sync Input
-
- Separate Sync
- Sync on Green
- Audio (In/Out)
-
- Headphone out
- PC audio-in
-
Convenience
- Built-in Speakers
- 1.5W x 2
- User convenience
-
- PowerSensor
- SmartImage
- Volume
- Menu
- Power On/Off
- Control software
- SmartControl
- OSD Languages
-
- English
- French
- German
- Italian
- Portuguese
- Russian
- Simplified Chinese
- Spanish
- Other convenience
-
- Kensington lock
- VESA mount (100x100mm)
- Plug & Play Compatibility
-
- DDC/CI
- Mac OS X
- sRGB
- Windows 8/7/Vista
-
Stand
- Height adjustment
- 130
mm
- Pivot
- 90 degree
- Swivel
- -65/65
degree
- Tilt
- -5/20
degree
-
Power
- ECO mode
- 12.3 W (typ.)
- On mode
- 18.3 W (typ.) (EnergyStar 7.0 test method)
- Standby mode
- <0.3 W (typ.)
- Off mode
- Zero watts with Zero switch
- Power LED indicator
-
- Operation — White
- Standby mode- White (blinking)
- Power supply
-
- 100-240VAC, 50-60Hz
- Built-in
-
Dimensions
- Product with stand (mm)
- 555 x 550 x 244
mm
- Product without stand (mm)
- 555 x 388 x 65
mm
- Packaging in mm (WxHxD)
- 632 x 457 x 286
mm
-
Weight
- Product with stand (kg)
- 6.97
kg
- Product without stand (kg)
- 4.64
kg
- Product with packaging (kg)
- 9.80
kg
-
Operating conditions
- Temperature range (operation)
- 0°C to 40°C
°C
- Temperature range (storage)
- -20°C to 60°C
°C
- Relative humidity
- 20%-80
%
- Altitude
- Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
- MTBF (demonstrated)
- 50,000 hrs (excluded backlight)
-
Sustainability
- Environmental and energy
-
- EnergyStar 7.0
- EPEAT Gold*
- PowerSensor
- RoHS
- Recyclable packaging material
- 100
%
- Recycled material
- 25%
- Specific Substances
-
- PVC / BFR free housing
- Mercury free
- Lead free
-
Compliance and standards
- Regulatory Approvals
-
- BSMI
- CE Mark
- FCC Class B
- GOST
- SEMKO
- TUV Ergo
- TUV/GS
- UL/cUL
- WEEE
- TCO 7.0
-
Cabinet
- Front bezel
- Black
- Rear cover
- Black
- Foot
- Black
- Finish
- Texture
-
What’s in the box?
- Monitor with stand
- yes
- Cables
- VGA, DVI, DP, Audio, Power
- User Documentation
- yes
